NB800-LWWtSu2Cn-G | NetModule

Keyfeatures

Factsheet

Mobile / Cellular

1x LTE, UMTS, GSM

SIM

1x Micro SIM / 1x eSIM chip (on request)

WiFi / WLAN

1x Dual-band IEEE 802.11a/b/g/n (Wi-Fi 4), 1x Bluetooth Low Energy

Ethernet

1x Fast Ethernet

Serial / Fieldbus

2x CAN active (read and write)

USB

USB 2.0 Host

Positioning

Multi-GNSS

Operation Temperature

-40 °C to +70 °C

Software

Routing, Network Services, VPN, Firewall, Link Management, Supervisor, SDK, free updates

Compliance

CE (RED), UKCA (RER), UL/IEC/EN 62368-1, FCC,

Modularity

Extensions on request

Description

The compact NB800 is the cost-effective solution for a robust Internet connection in an industrial environment. The small form factor and reduced features make it ideal for simple connectivity tasks. Its features include an LTE module for wireless Internet connection, a small WiFi access point with Bluetooth LE, two active CAN interfaces and an Ethernet port.

The high-quality metal housing, which is suitable for DIN rail mounting, in combination with the supported temperature range of -40 °C to 70 °C, offers the ruggedness required for use in industrial environments. The NB800 withstands mechanical and thermal stress. This, and its features, make the NB800 suitable for applications such Condition Monitoring, Smart Buildings, Environmental Monitoring, Industrial Security and Factory Automation.

The software is based on well proven components including an embedded Linux operating system and a powerful communication protocol suite as well as VPN technologies as OpenVPN. Customer specific software extensions may be implemented via a sophisticated SDK.

Product Information NB800 IIoT Routers

Applications

Condition Monitoring Industrial Security Factory Automation Remote Management Environmental Monitoring Intelligent Lighting Management Smart Buildings
